Onken 500 Gallon Low Profile Double Wall Used Oil Tank with Drain Box
Onken 500 Gallon Low Profile Double Wall Used Oil Tank with Drain Box
Onken's 500 gallon low profile double wall tank combines bulk used oil storage with a built-in drain area for busy service shops. A drain pan is welded onto the tank, so technicians can empty pans and containers straight into storage. At 33 in tall, the drain area stays at a comfortable working height.
Key features
- UL-142 listed for flammable liquids and NFPA 30 compliant
- 10 gauge steel double wall with 110% containment
- Robot welded and pressure tested
- 2 in suction tube with camlock fitting for pump-out
- Fluid level gauge and 2 in mushroom vent
- 60 x 96 x 33 in with a black powder coat finish
Good to know
The tank arrives assembled with the fittings and decals shown. It has no casters and is offered in black only as a limited production model, so minimum order quantities may apply. It ships by truck freight. Check local fire code for used oil storage at your site.
Specifications
| Brand | Onken |
|---|---|
| Model / part number | AZ2239-LP |
| Capacity | 500 gallons |
| Wall type | Double wall |
| Listings and approvals | UL-142, NFPA 30 compliant |
| For use with | Used oil |
| Style | Rectangular |
| Material | Steel |
| Steel gauge | 10 ga |
| Dimensions | 60 x 96 x 33 in |
| Pump included | No |
| Warranty | 1-year limited warranty against manufacturing defects |
| Ships from | Illinois |
| Lead time | 10 weeks |
Shipping and delivery
Freight is included to business addresses in the lower 48 states. Ships from Illinois. Lead time is 10 weeks. Liftgate delivery is available if you don't have a forklift or dock. Need several units or a delivered quote? Request a quote.
