Newberry 4000 Gallon Flameshield Double Wall Fuel Tank, UL-142
Newberry 4000 Gallon Flameshield Double Wall Fuel Tank, UL-142
The Newberry Flameshield 4,000 gallon tank is a tight-wrap double wall steel tank built to STI Flameshield requirements with a two-hour fire-tested design. It suits fleets, municipal yards and facilities that need bulk fuel storage with secondary containment built in. STI independent quality control inspections cover production, and the tank is designed for atmospheric pressure with proper venting.
Key features
- Built and labeled per UL-142 and SwRI 97-04
- Two-hour fire-tested performance with STI Flameshield and SwRI labels
- 64 in diameter x 24 ft long, approx. 6,574 lb
- 8 in NPT primary and secondary emergency vent openings
- 2 in NPT monitoring port for the interstitial space
- Blasted exterior with a white enamel shop coat
Good to know
Pumps, vents, gauges and fill or piping packages are sold separately. A tank this size needs a crane or heavy forklift on site to unload. Check local fire code, since some sites require a UL-2085 tank instead.
Specifications
| Brand | Newberry |
|---|---|
| Model / part number | NB04000FSD06407G |
| Capacity | 4,000 gallons |
| Wall type | Double wall |
| Listings and approvals | UL-142, SwRI 97-04, STI Flameshield |
| For use with | Diesel, Gasoline |
| Material | Carbon steel |
| Dimensions | 288 x 64 x 64 in |
| Weight | 6,574 lb |
| Pump included | No |
| Warranty | 1-year limited warranty |
| Ships from | Arkansas |
| Lead time | 24-26 weeks |
Shipping and delivery
Freight is included to business addresses in the lower 48 states. Ships from Arkansas. Lead time is 24-26 weeks. Plan for a forklift or similar equipment to unload it. Need several units or a delivered quote? Request a quote.
