Newberry 150 Gallon Double Wall Skid Fuel Tank, UL-142
Newberry 150 Gallon Double Wall Skid Fuel Tank, UL-142
This Newberry 150 gallon double wall skid tank is a compact UL-142 aboveground tank for diesel or gasoline. It suits small fleets, repair shops, farms and generator sites that need a modest fuel supply with secondary containment built in. The steel skids let it sit on a level pad without a separate stand.
Key features
- Built and labeled per UL-142 for aboveground storage of flammable and combustible liquids
- Steel outer wall surrounds the primary tank to provide secondary containment
- 30 in diameter x 48 in long inner tank in 12 gauge carbon steel
- Approx. 425 lb empty weight per Newberry's spec sheet
- 3 in NPT emergency vent openings for the primary and secondary tanks, plus a 2 in NPT monitoring port
- Ships in gray primer, with other colors and coatings available
Good to know
Pump, emergency vents, fill cap and gauges are sold separately. The tank ships by LTL freight, and liftgate delivery is available. Check local fire code and permit rules before installing a fuel tank.
Specifications
| Brand | Newberry |
|---|---|
| Model / part number | NB00150DWS03012G |
| Capacity | 150 gallons |
| Wall type | Double wall |
| Listings and approvals | UL-142 |
| For use with | Diesel, Gasoline |
| Style | Skid |
| Material | Carbon steel |
| Steel gauge | 12 ga |
| Dimensions | 48 x 30 x 38 in |
| Weight | 425 lb |
| Pump included | No |
| Warranty | 1-year limited warranty |
| Ships from | Arkansas |
| Lead time | 3-5 weeks |
Shipping and delivery
Freight is included to business addresses in the lower 48 states. Ships from Arkansas. Lead time is 3-5 weeks. Liftgate delivery is available if you don't have a forklift or dock. Need several units or a delivered quote? Request a quote.
