Newberry 1000 Gallon Double Wall Skid Fuel Tank, UL-142
Newberry 1000 Gallon Double Wall Skid Fuel Tank, UL-142
The Newberry 1,000 gallon double wall skid tank is a UL-142 aboveground tank sized for fleet yards, farms, job sites and backup power systems. The double wall steel design provides secondary containment, and the tank is 12 ft long overall on welded steel skids.
Key features
- Built and labeled per UL-142 for aboveground storage of flammable and combustible liquids
- 45 in diameter x 144 in long inner tank in 10 gauge carbon steel
- Approx. 2,025 lb empty weight
- 6 in NPT emergency vent openings for the primary and secondary tanks
- 2 in NPT openings for interstitial monitoring, pump and fill accessories
- Gray primer finish, with optional colors and coatings
Good to know
Pump packages, emergency vents, fill cap and gauges are sold separately. At about 2,025 lb, the tank ships by LTL freight and needs a forklift on site to unload. Check local fire code and permit rules before installing a fuel tank.
Specifications
| Brand | Newberry |
|---|---|
| Model / part number | NB01000DWS45510G |
| Capacity | 1,000 gallons |
| Wall type | Double wall |
| Listings and approvals | UL-142 |
| For use with | Diesel, Gasoline |
| Style | Skid |
| Material | Carbon steel |
| Steel gauge | 10 ga |
| Dimensions | 144 x 45 x 45 in |
| Weight | 2,025 lb |
| Pump included | No |
| Warranty | 1-year limited warranty |
| Ships from | Arkansas |
| Lead time | 3-5 weeks |
Shipping and delivery
Freight is included to business addresses in the lower 48 states. Ships from Arkansas. Lead time is 3-5 weeks. Plan for a forklift or similar equipment to unload it. Need several units or a delivered quote? Request a quote.
